| Module Name | DLP4500SL02 | |||
| DMD | TI 0.45〃WXGA DMD | |||
| Resolution | 1280x800 | |||
| Aspect Ratio | 16:10 | |||
| Light Source | R /G /B /W LED四选一 | |||
| Brightness | 350lm@白光 | |||
| Offset | 0% | |||
| Contrast Ratio | 1000：1 | |||
| Uniformity | >90% | |||
| Throw Ratio | 0.9：1 | 1.35：1 | 1.5：1 | 1.85：1 |
| Work distance | 200mm-1500mm | 150mm-1500mm | ||
| Distortion | <0.5% | |||
| Interfaces | Mini USB、Mini HDMI | |||
| Input power | DC 12V/3A | |||
| Total power | ＜30W | |||
| Dimension | 151mmx75mmx46mm | |||
| 镜头型号 | 焦距/mm | 光圈范围 | 最小投射面积mm | 最小工作距离mm | 最大投射面积mm | 最大工作距离mm | 畸变 |
| M1620-MPW2 | 16 | F2.0-F16.0 | \ | \ | 70.5*44 | 105 | 0.10% |
| M2518-MPW2 | 25 | F1.8-F16.0 | 38*24 | 85 | 100*62.5 | 250 | 0.10% |
| M3520-MPW2 | 35 | F2.2-F22.0 | 36*23 | 142 | 128*80 | 470 | 0.10% |
| M5028-MPW2 | 50 | F2.8-F32 | 52*33 | 303 | 189*118 | 1000 | 0.10% |
